Instruction Exhaust Fan Manuals For THUNDER LASER
Simple information about the Exhaust Fan on the THUNDER LASER machine.
Machine Series | Model of Machine | Model of Exhaust Fan | Diameter of Exhaust Duct |
NOVA Series | NOVA24 & 35 | HF-150PE | 150mm |
NOVA51 & 63 | HF-200PE | 200mm | |
THUNDER BOLT Series | THUNDER BOLT & | HF-100PE | 100mm |
THUNDER BOLT Pro 22 & 32 | HF-150PE | 150mm | |
AURORA Series | AURORA lite & | HF-100PE | 100mm |
MINI Series | MINI60 & 90 | HF-150PE | 150mm |
Specific information：
Please check the corresponding attached files.
End.
